Thermocouple XBAZA2107 - MWM 12322279

Thermocouple XBAZA2107 - MWM 12322279

for MWM TCG 2016 engines

Thermocouple OEM

References:

MWM

12322279 / 1232-2279 / 1232 2279

2G

32090-00008 2G 3209000008

engine:

MWM TCG 2016 V8

MWM TCG 2016 V12

MWM TCG 2016 V16

MWM TCG 2016 V16 C

Description:

Thermocouple With lose rotatavle screw conncetion, straight

Measuring element: NiCr-Ni, Typ K DIN EN 60584, Kl. 1

quality features:

number measuring element: 1

measuring tip diameter: Sheathed thermocouple Ø1,5x12 mm

material: Inconel 600

diamater 1: Ø5,5x12 mm

diameter 2: Ø6 (-0.01/-0.05)x10 mm

diameter 3: Ø6,7x66 mm

diameter 4: Ø10x11 mm

installation lenght: 99 mm to sealing washer

thread: M12x1 / 12 mm

material: srainless steel

cable lenght: 450 mm (cable and plug)

cable type: Teflon-Schirm-Silikon Ø5,0 mm / 2x0,5 qmm

connection: Cannon ITT plug MIL-5015/3-pol./10 SL/

assignment: A+, C-

equipment: Cu sealing washer I-Ø7,0x0,9 mm
