Oil filter MANN WD 13 145/4

Original MANN oilfilter WD 13 145/4
for various Jenbacher, Liebherr & MTU engines

Technical information:

Height: 302 mm
Outside diameter: 136 mm
Inside diameter upside: 100 mm
Inside diameter downside: 111 mm
Outlet/Thread size: 1 1/2-16 UN
Opening pressure bypass valve (bar): 2.50 bar

Cross-References:

Mann+Hummel:
6771659356
WD 13 145/4 / WD13145/4 / WD 131454 / WD131454
MTU:
003 184 42 01 / 0031844201 / 003-184-42-01 / 31844201
003 184 53 01 / 0031845301 / 003-184-53-01 / 31845301
MDE:
70400180301
Jenbacher:
224 404 / 224404 / 224-404
POWER SYSTEM:
470015
SDMO:
330510031 / FHU704
SULLAIR:
1939F4DC4
DETROID DIESEL:
5241800110
FIAC:
7212040000
Donaldson
P551402

Engines:

MTU
12V-20V 4000 L61
12V-20V 4000 L62
12V-20V 4000 L63
12V-20V 4000 L64
12V-20V 4000 L32
12V-20V 4000 L33
12V-20V 4000 L32FB
08V-20V 4000 L32FB
08V-20V 4000 L62FB


MANN oil filters:
Due the high quality of MANN-Filters, they are especially robust. They filter efficiently and reliably the circulating oil, because only a clean engine oil can ensure a lasting constant engine performance.
